● Customizable Solar Power Kit
● Delivers dependable energy even in low-light or shaded areas
● Eco-friendly and reliable energy source
● Flexible configurations to suit your needs
● Backed by a 25-year performance guarantee
Renogy's Custom Solar Kit is thoughtfully designed for RV owners, offering tailored solutions to match your unique travel and power needs. With a wide selection of configurations, you can build a solar setup that integrates perfectly into your RV lifestyle.
Power your adventures with ease—our kits come complete with durable, UV-resistant components built to withstand outdoor conditions. The integrated DC-DC charging system enables the solar panels to recharge both your house battery and your vehicle’s starter battery.
Say goodbye to the hassle of sourcing individual parts. Each kit includes everything you need in one convenient package.
*Performance based on average 5–6 peak sun hours.
100W 12V Solar Panel
Package Includes
| Solar Panel | Quantity*Title |
|---|---|
| 4*100W 12V Rigid Solar Panel | |
| 4*100W 12V Rigid Solar Panel (Black Division) | |
| 4*100W 12V Flexible Solar Panel | |
| 4*100W 12V Semi-flexible Solar Panel (Black Division) | |
| 2*200 Watt 16BB N-Type 24V Solar Panel | |
| 2*200W 12V Flexible Solar Panel | |
| Charge Controller
|
Quantity*Title |
| 1*12V 50A DC-DC On-Board Battery Charger with MPPT | |
| B |
| attery
|
Quantity*Title |
|---|---|
| 2*12V 100Ah Pro Lithium Battery w/Bluetooth & Self-heating | |
| 2*12V 100Ah Core Mini Lithium Battery w/ Self-heating Function | |
| Inverter | Quantity*Title |
| 1*2000W 12V Pure Sine Wave Inverter | |
| 1*2000W 12V Pure Sine Wave Inverter Charger & 1*Battery Inverter Cables for 3/8 in Lugs | |
| 1*300A ANL Fuse Set w/ Fuse | |
|
1*Fuse Cable |
|
| Accessory Set/Basic | Quantity*Title |
| 1*Solar Panel Mounting Z Bracket -- Set of 4(rigid solar panel) | |
| 1*Solar Y Branch Connectors MMF+FFM Pair | |
| 1*Solar Panel to Charge Controller Adaptor Kit | |
| 1*Battery to Charge Controller Tray Cables | |
| 1*Solar Double Cable Entry Gland | |
| Accessory Set/Premium | Quantity*Title |
| 1*Solar Panel Mounting Z Bracket -- Set of 4(rigid solar panel) | |
| 1*Solar Y Branch Connectors MMF+FFM Pair | |
| 1*Solar Panel to Charge Controller Adaptor Kit | |
| 1*Battery to Charge Controller Tray Cables | |
| 1*Solar Double Cable Entry Gland | |
|
1*BT-2 Bluetooth Module |
|
| 1*Holder w/ Fuse | |
| 1*ANL Fuse Set w/ Fuse | |
|
|
Max Power at STC: 100W
Open Circuit Voltage: 24.3V
Short Circuit Current: 5.21A
Optimum Operating Voltage: 20.4V
Optimum Operating Current: 4.91A
Operating Temperature: -40°F to 176°F
Maximum System Voltage: 600V DC (UL)
Maximum Series Fuse Rating: 15A
Dimensions: 41.8 x 20.9 x1.38 in
Weight: 14.1lbs/6.4kg
Max Power at STC: 100W
Open Circuit Voltage: 24.3V
Short Circuit Current: 5.39A
Opitmum Operating Voltage: 20.3V
Optimum Operating Current: 4.93A
Operating Temperature: -40°F to 194°F(-40°C to +90°C)
Maximum System Voltage: 600 VDC UL
Maximum Series Fuse Rating: 15A
Dimensions: 1100 x 509 x 35 mm (43.3*20.0*1.38 in)
Weight: 6.5 kg (14.5 lb)
Maximum Power at STC: 100W
Optimum Operating Voltage (Vmp): 18.9V
Open-Circuit Voltage (Voc): 22.5V
Optimum Operating Current (Imp): 5.29 A
Short-Circuit Current (Isc): 5.75 A
Operating Temperature: -40°F to 185°F (-40ºC to +85ºC)
Maximum Series Fuse Rating: 15A
Maximum System Voltage: 600V DC (UL)
Weight: 4.2 lbs (1.9 kg)
Dimensions: 48.0 x 21.6 x 0.08 in (1219 x 546 x 2 mm)
Maximum Power at STC: 100W
Optimum Operating Voltage (Vmp): 19.4V
Open-Circuit Voltage (Voc): 23.5V
Optimum Operating Current (Imp): 5.20A
Short-Circuit Current (Isc): 5.51A
Operating Temperature: -40℃ to 80℃ (-40℉ to 176℉)
Maximum Series Fuse Rating: 15A
Maximum System Voltage: 600V DC
Weight: 2.4 kg / 5.3 lbs
Dimensions: 1093 x 582x 2.5mm (43 x 23 x 0.1 in)
Maximum Power at STC: 200W
Optimum Operating Voltage (Vmp): 31.03V
Open-Circuit Voltage (Voc): 37.44V
Short Circuit Current: 6.85A
Optimum Operating Current (Imp): 6.45A
Maximum System Voltage: 600V DC
Maximum Series Fuse Rating: 15A
Operating Temperature: -40°F~185°F / -40℃~85℃
Dimensions: 1262x764x30mm/49.7x30.1x1.2in
Weight: 10.6kg/23.4lbs
Maximum Power at STC: 200W
Open-Circuit Voltage (Voc): 23.9V
Short Circuit Current: 10.74A
Optimum Operating Current (Imp): 10.02A
Maximum System Voltage: 600V DC
Maximum Series Fuse Rating: 15A
Operating Temperature: -40°F to 176°F (-40ºC to +80ºC)
Dimensions: 1605 x 748 x 3 mm (63.2 x 29.4 x 0.1 in)
Weight: 4.9 kg / 10.8 lbs
opc:
System Voltage: 12VDC
Maximum Charging Current: 50A
Battery Types: SLD, GEL, FLD, LI,USER
Service Battery Charging Mode: MPPT
Charging Efficiency: Up to 97%
Max. Solar Input Voltage: 25V
Max. Solar Input Power: 660W @ 50A
Terminal Size: M8*1.25 - 10mm
Ground Type: Negative
Operating Temperature Range: -31°F - 149°F
Storage Temperature Range: -40°F - 176°F
Dimensions: 9.6*5.7*3.0in
Weight: 3.13Ibs
Communication Protocol: RS485
Battery Type: Lithium Iron Phosphate
Rated Capacity: 100Ah (0.5C, 25℃)
Nominal Voltage: 12V
Voltage Range: 10V to 14.8V
Cycle Life(0.5C,25℃): 5000 Cycles (80% DOD, 80% EOL)
Connection Method: Parallel (Up to 8)
Protection Rate: IP67
Maximum Charge Current: 100Ah
Maximum Discharge Current: 100Ah
Peak Discharge Current: 245A@30s
Charge Temperature: -4°F to 131°F (-20°C to 55°C)
Discharge Temperature: -4°F to 140°F (-20°C to 60°C)
Communication Port: Bluetooth
Dimensions: 10.6 x 7.6 x 8.1 in (268 x 193 x 205 mm)
Weight: 26.9 lbs. (12.2 kg)
opc:
Battery Type: Lithium Iron Phosphate
Rated Capacity: 100AH
Voltage: 12V
Cycle Life (0.5C, 77°F/25°C): 5000 Cycles (80% DOD)
Connection Method: Series & Parallel (up to 4S4P)
Protection Rate: IP65 (Dust-tight & splash-resistant)
Charge Voltage: 14.6V
Maximum Charge Current: 100A
Maximum Continuous Discharging Current: 100 A
Charge Temperature Range: -22°F to 131°F (-30°C to 55°C) – Ideal for safe charging
Discharge Temperature Range: -4°F to 140°F (-20°C to 60°C)
Terminal Bolt Size: M8 x 1.25 × 12 mm
Dimensions: 9.02 × 5.43 × 8.39 in (229 × 138 × 213 mm)
Weight: 21.38 lbs (9.7 kg)
Continuous Power: 2000W
Peak Power Rating: 4000W
Output Voltage: 1150V
Output Frequency: 60 Hz ± 0.1%
AC Output Sockets: 3
AC Terminal Block: 1
USB Power Port: 5V/2.1A
Power Output Control: AC On/Off Switch, and Remote Control
Output Waveform: Pure Sine Wave
Nominal Efficiency: > 90%
Operating Temperature Range: -4°F - 104°F
Cooling Fan: Thermally controlled
Dimensions: 17.8 x 8.6 x 4 in
Weight: 11.7 lbs
Continuous Power: 2000W
AC Output Voltage Range: 100~120VAC configurable, 5V interval
DC Input Voltage Range: 10~16 VDC
Nominal Efficiency: > 90% Peak
Output Waveform/repea11: Pure Sine Wave
Output Frequency : 50/60 Hz
Input Voltage Range: 90-138 VAC
Input Wave Form: Sine Wave (Utility or Generator)
Operating Temperature: 0 ~ 40°C / 32 ~ 104°F
Storage Temperature: -30 ~ 70°C / -22 ~ 158°F
Battery Types: GEL, AGM, SLA, FLD, CAL, LI, USER
Dimensions: 20.1 x 11.2 x 7.6 in / 510 x 285 x 193 mm
Weight: 51.1 lbs / 23.2 Kg
opc:
Panels: 25-year power output warranty: 5 year 95% output warranty, 10 year 90% output warranty, 25 year 80% output warranty 10-year material and workmanship warranty
Accessories: 1-year material and workmanship warranty
